Aputure Spotlight Max 19 kit

Aputure Spotlight Max 19 kit

The Spotlight Max is a Bowens mount projection spotlight designed to be used with high-output LED point source lamps between 600W and 2600W of output such as the LS 600d Pro and the ElectroStorm XT26.

With custom precision optics, the Spotlight Max concentrates and efficiently blends light into a single, clean beam while maintaining its light source’s colour accuracy and mitigating chromatic aberration. The use of telecentric optical elements in the Spotlight Max ensures that the difference of the output field angle and beam angle are minimized, resulting in an illumination circle with even edge-to-edge light distribution, without any hotspots.

Spotlight Max is available with 19°, 36°, and 50° lenses, allowing it to cover a wide range of light projection needs on set. Included in the Spotlight Max Kit is a Rotatable Gobo Clip that accepts A-Size Gobos (3 included), B-Size Gobos, and Rosco
metal and glass gobos. The built-in four-leaf cutter gives users even more control
when shaping light output. Using a separately available Spotlight Max Iris, users also may quickly reduce the illumination circle size without needing to change projection
lenses or physically move the fixture set up. Featuring a detachable yoke, the Spotlight Max can be easily be mounted in upright or underslung positions, allowing for
maximum rigging flexibility.

To maximize compatibility, the Spotlight Max comes with a durable Bowens mount and may be used with a separately available ETC Lens Adapter, allowing the Spotlight Max to be paired with any Bowens mount fixture on the market and ETC projection lenses.
The Spotlight Max includes a reinforced hard rolling case, making transportation and storage easy and safe.

The Aputure Spotlight Max is a powerful projection lens ideal for professional film-makers and lighting technicians looking to achieve a tight and intense beam of light with a long throw using high-output Bowens mount fixtures. Users who require highly colour-accurate light projections and evenly-lit illumination circles will appreciate the custom precision optics in the Spotlight Max that maintains the colour accuracy of its light source as well as minimizes chromatic aberration.

Film-makers that need to texture and shape their lights will find the Spotlight Max’s built-in cutters, the included Rotatable Gobo Clip and A-Size Gobos to be convenient
and time-saving accessories. In addition, users who value flexibility and compatibility will find the detachable yoke design and the Bowens mount to be ideal for expanding rigging and modifier options. The Spotlight Max offers stellar optical projection
performance and compatibility with high-powered fixtures, making it a crucial addition to any professional film-maker's and lighting technician’s tool kits.

• Projector Lens Modifier for High-Powered Bowens
Mount LED Fixtures
• 19° / 36° / 50° Lenses Available
• Compatible with ETC Projection Lenses Via Separately Available ETC Lens Adapter
• Custom Precision Optics With Minimal Chromatic Aberration and Colour Shift
• Efficient Light-Blending Optical Design for Compatibility with Full-Colour Fixtures
• Telecentric Element Groups for Even Edge-to-Edge Light Distribution and Minimal Distortion of Illumination Circle
• Spotlight Max Iris Separately Available for Fine Tune
Control of Illumination Circle Size
• Advanced Internal Matting Minimizes Light Leaks Within the Projector Barrel
• Detachable Yoke for Ultimate Rigging Flexibility
• Included Rotatable Gobo Clip Compatible with A and B-Size Gobos along with Rosco Metal and Glass Gobos
• Rotatable Gobo Clip Allows for Easy Adjustment of Light Texture
• Built-In 4-Leaf Cutter for Precise and Subtle Light Shaping
• Durable All-Metal Build
• Included Flight Case for Maximum Protection

Spotlight Max 19° Specifications

Dimensions Without Yoke
48.3 x 25.0 x 25.0cm
19.0 x 9.8 x 9.8in
With Yoke
48.9 x 25.0 x 50.1cm
19.3 x 9.8 x 19.7in
Weight Total 12.44kg / 27.43lbs

What’s in the box

• Spotlight Max x 1

• Spotlight Max Yoke x 1

• Spotlight Max 19° Lens x 1

• Rotatable Gobo Clip x 1

• A-Size Gobo x 3

• Rolling Hard Case x 1
